Amfibie-Bil (ATV)
Avenger 8 x 8
Engine 4 cycle overhead valve V-Twin gasoline engine,electronic ignition,
solenoid shift started,fuel accelerator pump,full pressure lubrication and oil filter.
3 year warranty
Model : Kohler Aegis LH 685
Horsepower : 25
Displacement :674cc
Cooling : Liquid Cooled
Starting : Electric
Brakes : Hydraulic
Steering : One-piece ergonomic handlebar steering control with
mounted brake lever and parking brake.
Controls : Right-hand twist grip throttle and dash mounted choke control.
Light switch and ignition switch.
Clutch & Transmission Belt-driven,
Continuously Variable Transmission (CVT) maximizes engine power
to the transmission with high and low range forward, neutral and reverse,
compactly housed with an efficient planetary differential.
Drive System : Roller chains drive machined sprockets
that are spline-fit onto 1.25" diameter axles.Bearings are greaseable and
are protected with double-sealed outer flange assemblies.
Frame : Formed steel channel construction,
welded for high strength and durability.
Polyester powder coated for lasting protection.
Body : Vacuum formed High Density Polyethylene (HDPE)
Full Skid Plate Standard
Load Capacity on Land (without accessories) 1150 lbs / 521 kg total.
No restrictions for rear compartment
Towing Capacity : 1800 lbs / 818 kg
Seating Capacity : 6 persons on land, 4 persons on water
Fuel Capacity See-through polyethylene fuel tank, 29 L
(7.7 US gallons/6.4 Imp. Gallons), 8 hours of operation.
Speed (on land) : 22 mph /35 km per hour
Speed (on water) : 2.5 mph / 4 km per hour
Shipping Weight :1205 lbs / 547kg
Axle Bearing Extensions Front and Rear Standard
Hourmeter Standard
Voltmeter Standard
Temperature Gauge Standard
Low Charge Rate Light Not Available (yet)
Low Oil Pressure Light Standard
Tire Goodyear Rawhide III AT25 x 11.50-9 NHS
Ground Pressure 2.1 psi (14.5 kPa) using tires,
0.67 psi (4.6 kPa) using tracks
Operating Conditions :
All weather,all-terrain,-40°C to +40°C
